Processor
Intel Core i3-6100U processor (2.3 GHz, Dual Core, 3 MB Cache, 15W TDP)
Memory
Dual Channel DDR4 SODIMMs
1.2V 2133MHz, 32GB Maximum
Graphics
Intel HD Graphics 520
1 x Full Size HDMI 1.4b
1 x Mini DisplayPort 1.2
Audio
UP to 7.1 Surround Audio via HDMI and Mini DisplayPort
Headphone/Microphone Jack on the Front Panel
Peripheral Connectivity
2 x USB 3.0 Ports on the Back Panel
2 x USB 3.0 Ports on the Front Panel (1 x Charging Capable)
2 x Internal USB 2.0 Via Header
Consumer Infrared Sensor on the Front Panel
Storage
Internal Support for M.2 SSD Card (22x42 or 22x80)
SDXC Slot with UHS-I Support on the Side
Networking
Intel 10/100/1000Mbps Network Connection
Intel Wireless-AC 8260 M.2 Soldered-Down, Wireless Antennas (IEEE 802.11ac, Bluetooth 4.1, Intel Wireless Display 6.0)
Enclosure
Silver with Black Top and Diamond Cut around the Top
Aluminum and Plastic
Power Adapter
19V, 65W Wall Mount AC-DC Power Adapter
Multi-Country Plugs (IEC Types A/C/G/I)
Additional Features
Support for User Replaceable 3rd Party Lids
NFC and AUX_PWR Header
OS Certs: Windows 10, 8, 8.1 Logod
OS Compatibility: Ubuntu, Linux Mint, Fedora, Open SUSE
VESA Mount Bracket and Mounting Hole Support
Low Acoustics Active Cooling Design
Kensington Lock with Base Security
Integrated Guide
12-19V DC Power Input
3-Year Advanced Warranty Replacement
Package Contents
Intel NUC Kit NUC6e3SYK Integrated in Enclosure:
VESA Mount Bracket and Mounting Hole Support
19V, 65W Wall Mount AC-DC Power Adapter with Multi-Country AC Plugs
Integrated Guide
Processor Badge
Item Dimension (L"xW"xH")
5 x 5 x 4
Weight
1.00 lb
Warranty Information
3 Years Limited
